444 Stainless steel tube manufacturer
SUS444 (00Cr18Mo2) is a ferritic stainless steel with
ultra-low carbon and nitrogen content, 18% chromium and 2%
molybdenum, and high corrosion resistance.The yield strength
of 444 is equivalent to 1.5 times of carbon steel and 6
times of fiberglass steel. It has outstanding advantages in
shock resistance, snow resistance, wind pressure resistance
and impact resistance.
SUS444 ferritic stainless steel
has high thermal conductivity, about 130% ~ 150% of Cr-Ni
austenitic stainless steel, which is very suitable for heat
exchange purposes.
Small thermal expansion coefficient,
the small unit is only 60% ~ 70% of chromium-nickel Olympic
stainless steel, very suitable for hot expansion, cold
shrinkage, thermal cycle conditions.
The steel has good
plasticity and toughness and is suitable for drawing,
rolling forming and stamping manufacturing.
Especially
the application of corrosion resistance is the most
excellent, in the high chloride medium corrosion resistance
is better than ordinary ferrite stainless steel and Olympic
stainless steel, generally do not produce chloride stress
corrosion cracking.
When Ti and Mo elements are added,
the resistance to pore and crevice corrosion is
improved.
The steel can be welded by the method of
welding ordinary stainless steel.
This kind of steel is
especially suitable for food processing equipment, heat
exchanger, water heater tank, water storage tank, solar
energy collection panel, etc.
444 Stainless steel tube Price in China ,Manufacturer of 444 Stainless Steel tube
444 stainless steel has the ability of oxidation resistance
to corrosion, but has the tendency of intergranular
corrosion.
444 stainless steel wire is widely used in the
axis.
As safe and non-toxic, it is widely used in food
tableware.
This is the most cost effective grade of steel. So the 444 Stainless Steel tube Price is lower compared to other grades of stainless steels and all metallic products in general. There are different versions of the material with low carbon and high carbon content. The low carbon version, 444 tubes are very good for welding applications as they have less carbide precipitation and less localized corrosion.
Equivalent Material of 444 Stainless Steel tube
| Grade | Euronorm | China GB | Japanese JIS | |
| No. | ||||
| 444 | 1.4521N | 00Cr18Mo2 | SUS444 | |
Standard Specification Of 444 tube
| Thickness | 0.5mm-100mm | ||||||
| Outer diameter | 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Round tube Square tube Rectangular tube etc. | ||||||
444 stainless steel composition content.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 444 | Min. Max. |
≤0.025 | ≤1.00 | ≤1.00 | ≤0.04 | ≤0.03 | 17.5~19.5 | 1.75~2.5 | ≤1.00 | ≤0.035 |
Common Types Of 444 Stainless steel tube
-
444 Stainless steel tube
-
444 Stainless steel tube
-
444 Stainless steel tube
Dimensions Standard,weight chart and size schedules of 444 stainless steel Tube
| SS 444 Tube Size(mm) | SS444 Tube Weight per Unit Area(kg/m) | |||
| 6*1 | 0.125 | |||
| 6*1.5 | 0.168 | |||
| 8*1 | 0.174 | |||
| 8*1.5 | 0.243 | |||
| 10*1 | 0.224 | |||
| 10*1.5 | 0.318 | |||
| 12*1 | 0.274 | |||
| 12*1.5 | 0.392 | |||
| 12*2 | 0.498 | |||
| 14*1 | 0.324 | |||
| 14*2 | 0.598 | |||
| 14*3 | 0.822 | |||
| 16*2 | 0.697 | |||
| 16*3 | 0.971 | |||
| 17*3 | 1.046 | |||
| 18*1 | 0.423 | |||
| 18*1.5 | 0.617 | |||
| 18*2 | 0.797 | |||
| 18*3 | 1.121 | |||
| 20*1 | 0.473 | |||
| 20*2 | 0.897 | |||
| 20*3 | 1.27 | |||
| 21*3 | 1.345 | |||
| 22*2 | 0.996 | |||
| 22*2.5 | 1.214 | |||
Price list
| Stainless Steel 444 tube Price List | 444tube FOB Shanghai Per Unit (USD) | |||||||
| 2mm 444 stainless steel tube | $1500.00-$2000.00 | |||||||
| ss 444 mirror Stainless Steel Coil/ Strip/ tube | $1800.00-$2300.00 | |||||||
| 444 Stainless Steel tube / Stainless Steel tube 444 | $1500.00-$2000.00 | |||||||
| Standard size 4×8 metal sus 444 grade stainless steel tube prices | $1500.00-$2000.00 | |||||||
